Vertical splice closure
Vertical splice closure Vertical splice closure Vertical splice closure

Vertical splice closure

Product ID : VDX-SP-05
Product Tags :
Product Attributes :

Fiber Optic Splice Closure is of
innovative bullet shape, smooth and solid
shell; the device is equipped with holt hoop
iron seal device in the drum and base, and
elastic seal ring at the bottom of the drum,
which shall provide reliable, stable and flexible
protection for the direct, terminal or branching
connection of the fiber.

Product Description

Application:
                  Ο direct burying   Ο man well
  Ο hand hole    Ο wall-cling Ο hold pole
Properties:
         Aging resistance: stable in heat, heat energy radiation, air, ozone, etc.
         Corrosion resistance: resistant to diluted acid, saline water, oxidant, aliphatic
hydrocarbon, etc.
         Seal technique: spiral taper seal technique, waterproof, moistureproof and airtight.
         Mechanical properties: resistant to shake, bump, draw & distortion of the optical
cable and intense temperature change, etc.
         Locking device: require no special tools, easy installation and operation.

  Branching function: the two-in-two-out design at the two terminals provides multiple inlet-outlet options for the butt connection and direct connection of the fiber.
         Connection function: layered structure, two inlet-outlet holes for fiber for the sake of management convenience.
Capacity:
         Capacity of the connection tray: single-core bunch 12 cores/tray, double-core bunch 24 cores/tray, belt (4, 6, 8, 12 cores) 6 units/tray.
         Maximum capacity: can accommodate as much as 7 connection trays.
         Optical cable inlet-outlet hole: there are six optical cable inlet-outlet holes in the base and the maximum 6 holeS can accommodate four optical cables with their diameter no more than 23mm.
Schematic diagram for the accessories:
         Please refer to the packing list for the name of the accessories in the diagram.
Product Directory:

Product Name
Dimension
12-core tray singlecore(capacity)
24-core tray doublecore(capacity)
4, 6, 8, 12 core belt (capacity)
GJS10-K Fiber Optic Splice Closure
H470X Φ160
12 cores
24 cores
24、36、48、72 cores
GJS10-K Fiber Optic Splice Closure
H470X Φ160
24 cores
48 cores
48、72、96、144 cores
GJS10-K Fiber Optic Splice Closure
H470X Φ160
36 cores
72 cores
72、108、144、216 cores
GJS10-K Fiber Optic Splice Closure
H470X Φ160
48 cores
96 cores
96、144、192、288 cores
GJS10-K Fiber Optic Splice Closure
H470X Φ160
60 cores
120 cores
120、180、240、360 cores
GJS10-K Fiber Optic Splice Closure
H470X Φ160
72 cores
144 cores
144、216、288、432 cores
GJS10-K Fiber Optic Splice Closure
H470X Φ160
84 cores
168 cores
168、252、336、504 cores

Notes: please make clear bunch or belt in the order (the belt can be divided into 4-core, 6-core, 8-core and 12-core).
