Insertion loss:""SM MTP≤0.7dB, LC≤0.2dB MM MTP≤0.5dB, LC≤0.2dB""Number of fiber cores:24
product name:MPO-LGX-12SCFiber type:SM or MM optional
colour:blackBackend connector:2xMTP/MPO (male)
Operating temperature:0°C~70°C (32°F~158°F)Storage temperature:—40°C~+75°C (-40°F~167°F)
RoHS compliant:meetsSize (HxWxD):
MTP adapter:Convex-concave keyReturn loss:""SM MTP ≥ 50dB, LC ≥ 50dB MM MTP ≥ 20dB, LC ≥ 35dB""
Front connector:12xLC duplexTypes:LGX
