Product Description
|
Range of Mode |
Single mode or Multi mode |
|
Cable Type |
Simplex, Duplex Ziocord. or Multi-cores |
|
Connector Style |
SC, FC, ST, LC, MTRJ, E2000, MU, MPO /MTP.etc |
|
Polish or Ferrule Interface Type |
PC, UPC, APC |
|
Cable Diameter |
0.9mm, 1.2mm, 1.6mm, 1.8mm,2.0mm, 3.0mm |
|
Outer Jacket |
PVC /LSZH/OFNP |
|
Jacket Color |
SM Yellow | OM1, OM2 Orange | OM3 Aqua | OM4 Aqua or Violet | OM5 Lemon Green |
|
Durability |
500 cycles(0.2 dB max increase). 1000mate/de mate cycles |
|
Operating Temp. |
-20 ℃ to +70℃/+85℃ (armored) |
|
Storage Temp. |
-40℃ to +85℃ |
Technical Data
|
Connector Type |
Performance Level |
|||||
|
Standard |
Elite |
|||||
| Connector | Mode | Endface | IL(dB) | RL(dB) | IL(dB) | RL(dB) |
| LC/SC/FC/ST | SM | PC | ≤0.2 | ≥50 | ≤0.15 | ≥50 |
| UPC | ≤0.2 | ≥55 | ≤0.15 | ≥55 | ||
| APC | ≤0.2 | ≥60 | ≤0.15 | ≥60 | ||
| MM | PC | ≤0.2 | ≥35 | ≤0.15 | ≥35 | |
| MPO/MTP | SM | APC | ≤0.7 | ≥60 | ≤0.35 | ≥60 |
| MM | PC | ≤0.5 | ≥20 | ≤0.35 | ≥20 | |
| MTRJ | SM | PC | ≤0.5 | ≥50 | / | / |
| MM | PC | ≤0.5 | ≥35 | / | / |
|
